Accsoon CineView HE set (RX+TX)
Product number:
SW28278
Accsoon CineView HE
Accsoon CineView HE is an HDMI Dual-Band long range wireless camera transmitter and receiver kit featuring a new USB-C port on receiver for live streaming directly (UVC). It transmits HD video and HQ audio to up to 4 devices (its receiver, mobile phone, iPad, and even MacBook with the newest M1 chip) through Accsoon’s uniquely patent Dual-Band (2.4GHz + 5GHz) transmission technology. And its brand new USB-C port on the receiver will provides creators, live streamers, and podcasters with much more power to display their work or life through live streaming.
Transmitter data
- Video Input: HDMI
- HDMI Input Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fps
- HDMI Output Format: 1080p 23.98/24/25/29.97/30/50/59.94/60fps
- DC Port: 5.5mm x 2.1mm center positive
- DC Voltage: 7.4~16.8V =Audio: 44.1KHz/48KHz 16bit/24bit PCM
- Latency: <0.06s (Camera latency not included)
- OLED Display: 1.3inch
- Transmission Power: 17~20dBm
- Transmission Range: 1200ft (No obstacles, no interference)
- Power Consumption: 4.5Watt (Typical)
- Operating Environment Temperature: -10°C~40°C
- Dimensions: 105mm x 66mm x 32mm (Antennas not included)
- Weight: 200g (Antennas included)
Receiver data
- Video Output: HDMI
- HDMI Output Format: 1080p 24/25/30/50/60fps
- DC Port: 5.5mm x 2.1mm center positive
- DC Voltage: 7.4~16.8V
- OLED Display: 1.3inch
- Power Consumption: 4.2Watt (Typical)
- Operating Environment Temperature: -10°C~40°C
- Dimensions: 105mm x 66mm x 32mm (Antennas not included)
- Weight: 200g (Antennas included)
