Core SWX CUBE-PLV Cube Plus V-mt 120W Power Supply
€539.00*
Free shipping
Available, delivery time: 1-3 days
Core SWX CUBE-PLV
Core’s Cube Plus is a lightweight, all aluminum 120w on-board power supply capable of powering a camera or device, while simultaneously charging an on-board battery pack up to 3A (depending on the power supply load, charge speed may reduce) per hour(~2hrs to fully charge a 98wh pack).
The Cube Plus, when having an on-board pack mounted, is designed to act like an uninterruptable power source should AC mains power be disconnected. Not only will the device switch from AC to on-board power for the camera or device, but the two p-tap connections are also backed up.
The Core SWX Cube Plus has internal protections along with a replaceable 10A fuse. It accepts 100-240VAC, making it useable worldwide and it includes an AC power cord. Furthermore, it’s fan-less, and operates silently.
Features
Lightweight, all aluminium 120w on-board power supply
Mounts on to a camera or device like a battery pack
2x ptaps to power accessories(powered by both power supply or on-board battery)
Acts like a UPS if AC mains is disconnected(as long as an on-board battery is mounted)
Simultaneous charges a battery pack while powering a camera/device*
Red and green status LEDs for charge and power to camera/device
All Aluminium design
90-240 VAC worldwide compatible input voltage
Fanless and operates silently
Technical data
DC Output: 120W max(14.3v) to camera mains connection and 2x ptap.
Quick Charge Current: up to 3A*
Protection: Over Current, Voltage & Temperature
Dimensions:121,9 mm x 94 mm x 83,8 mm
Weight: 0,5 kg
Input Voltage: AC 100-240V 50/60Hz
