Metabones Canon EF to MFT T Smart Adapter

Metabones Canon EF to MFT T Smart Adapter

SKU: MB_EF-m43-BT2

Starting from firmware V1.7, autofocus is enabled on Panasonic camera bodies, subject to certain limitations. The Panasonic Micro Four Thirds camera bodies are capable of autofocusing fast (large maximum aperture) lenses accurately. Although first and foremost priority is accuracy, Metabones is able to make great strides in autofocus speed as well, which is significantly faster than a DSLR Four Thirds lens on a Panasonic Micro Four Thirds camera (with adapter).

Some improperly-made M42 screw mount adapters may short the electronic contacts of the Metabones Smart Adapter and cause damage to the Smart Adapter and/or camera body.

Focus confirmation "chips" such as Dandelion are incompatible.

Many manual focus lenses (e.g. OM 28/2.8, OM 50/1.8, Leica R 15/3.5) have rear protrusions (spikes, levers, other appendages) which would damage the housing of Smart Adapter. They need to be modified before they can be safely used on Smart Adapter. Check and make sure there are no rear protrusions from the adapter/lens combination before using on Smart Adapter. Scratches and damages caused by rear protrusions on Smart Adapter are not covered by warranty.

List of manual focus lenses which REQUIRE MODIFICATION to be used on Smart Adapter

Leica R
Super-Elmar-R 15mm
Elmarit R 28/2.8
Elmarit R 35/2.8
Summicron R 50/2
Nikon F20/2.8 AI-SOlympus OM
OM 18/3.5
OM 21/2
OM 21/3.5
OM 28/2.8
OM 50/1.8
Pentax KEvery Pentax K-mount lens has a protruding fin and an aperture lever. It does NOT fit.

Features

Electronic
Auto focus on Panasonic Mirco Four Thirds cameras
Can be powered either by camera body or by third-party external 5V power source (not included)
Iris/aperture controlled by the camera body.
Image stabilization (IS) lens support
Electronic manual focusing (e.g. EF 85/1.2L II and discontinued EF 50/1.0L)
EXIF (focal length, aperture, zoom range)
Distance and zoom display on camcorders (requires lenses supporting distance information)
Other
Detachable tripod foot compatible with Arca Swiss, Markins and Photo Clam ball heads.
Flocking material coating inside the opening to reduce internal reflection.
Supports EF-S lenses.
Limitations
No autofocus support for JVC and Olympus
AFC (continuous AF) and AFF (flexible AF) modes are not supported
Video AF may hunt more than a native lens
No support for in-camera correction such as peripheral shading, CA and distortion

Autofocus Lens Compatibility List

Accurate
Canon EF-S17-55mm f/2.8 IS USM
Canon EF-S18-55mm f/3.5-5.6 IS II
Canon EF20-35mm f/3.5-4.5 USM
Canon EF24-105mm f/4L IS USM
Canon EF35-80mm f/4-5.6
Canon EF40mm f/2.8 STM
Canon EF50mm f/1.2L USM
Canon EF50mm f/1.4 USM
Canon EF70-200mm f/2.8L IS II USM
Canon EF70-300mm f/4-5.6L IS USM
Canon EF85mm f/1.2L II USM
Canon EF100mm f/2.8 USM macro
Sigma 18-35mm f/1.8 DC Art
Sigma 18-125mm f/3.8-5.6 DC HSM
Tamron SP 24-70mm f/2.8 Di VC USD A007
Tamron SP 70-200mm f/2.8 Di VC USD A009
Tokina AT-X PRO 11-16mm f/2.8 DXII
Accurate only on newer cameras such as Panasonic G7
Canon EF70-200mm f/4L USM
Canon EF135mm f/2L USM
Canon EF200mm f/2.8L II USM
Inaccurate
Canon EF50mm f/1.8 II
Sigma 50mm f/1.4 EX HSM
Manual focus only
Contax N lenses modified by Conurus
Tamron SP 17-50mm f/2.8 VC B005
Zeiss ZE lenses
