Middle Things Fiber Camera Box PTZ 12G SLAVE
Middle Things Fiber Camera Box PTZ 12G
Compact dual channel optical converter which transforms a double 4K SDI In + 4K SDI Out + LAN IP 1G signal into a single optical fiber cable through a robust Neutrik OpticalCon Duo connector. It is very similar to the Fiber Camera Box 12G, the only difference is the added 1G LAN port at the back, which makes it ideal for PTZ cameras!
The Fiber Camera Box PTZ 12G (Slave) can be used with the Middle Things Dispatch 4 PTZ 12G or the Fiber Camera Box SDI 12G (Master). The Fiber Dispatch 4 is not required. Two Fiber Camera Box PTZ can be connected together, but please note that a Slave unit has to be used with a Master and vice versa. You cannot connect a Slave to a Slave or a Master to a Master. The Dispatch 4 PTZ acts as a Master device. Other than this compatibility difference, the Slave and Master are exactly the same unit in terms of features. Supported SDI video signals are 3G, 6G, and 12G (max 2160p60 )
Technical Specifications
- I/O connections: 12-24V DC IN , SDI IN , SDI OUT (up to 6G) , Neutrik OpticalCon Duo LC
- Input Voltage : 12-24V DC
- Fiber type : Single Mode
- Dimensions :18cm x 10.5cm x 3.5cm
- Weight : 360g s
- Storage Temperature : -10 to 60°C
