RGBlink Aura UHD 27 Gen 2 27" Production Monitor

RGBlink Aura UHD 24 RGBlink Aura UHD 24 is 24" broadcast/grading 4K HDR monitor, equipped with UHD (3840×2160) screen, supports 4-channel single-link 12G-SDI, quad-link 4K SDI and HDMI2.0 signal input, it supports high-precision 3D LUT with tetrahedral interpolation algorithm and HDR formats such as SMPTE ST2084(PQ), hybrid log-gamma HLG, various Gamma curves , camera Log and other professional functions which are widely used in pre-shooting and post-grading work in broadcasting, film, television, and high-end advertising production. The 24" RMS UHD Production Monitor adopts a high-precision 3D LUT that supports tetrahedral interpolation algorithm, and built-in Rainbow color management engine to ensure accurate color reproduction. Features 12G-SDI /8K/4K HDMI Signal4K IPS LCD PanelProfessional On Set Monitoring ToolsFlexible and Intuitive Button OperationAccurate 3D LUT Color CalibrationMultiple Screen ModesSDR and HDR Image Comparison Function12G-SFP Fiber PortUSB-C (Thounderbolt) input PortAluminum Alloy FramePayload ID Automatically Read3D LUT, Recreate Film LooksDynamic UMDThree Color Tally LightsProfessional Audio MetersRemovable feet and handles on the back sideVESA mounting points

RGBlink Aura UHD 24 Gen 2 This next generation 24" broadcast/grading 4K HDR monitor, equipped with UHD (3840×2160) screen, supports quad link 12G SDI signal up to 8K input backward compatible with 4K@60Hz, high-precision 3DLUT with tetrahedral interpolation algorithm, HDR formats such as SMPTE ST2084(PQ), hybridlog-gamma HLG, various Gamma curves, camera Log and other professional functions which are widely used in film, television and advertisement industry.When you need high quality SDI monitoring for 4K or 8K video, RMS UHD series is the perfect choice. It comes with four 12G-SDI in- and outputs and supports up to 8K signal input. There are multiple possible configurations of input with two HDMI 2.0 inputs that support 4096x2160p and 3840x2160p up to 60p. Corresponding to the refreshrate of 60 frames per second, 4K audio and video transmission can be solved just over a single cable, reducing costs and ensuring high quality image, bringing you a new visual experience!The 4K UHD LCD panel, with ultra high resolution and color depth up to 10bit displays 1.07B colors, that allow you to see a color performance you have never seen before providing more creative space for color grading. This UHD Monitor covers 100% Rec.709 and 98% DCI-P3 wide color gamut, presenting rich color and supports ITU-R BT.2020, ITU-R BT.709, EBU, SMPTE-C, Native and other color gamuts. It offers a series of professional auxiliary monitoring tools, such as waveform, 3D-LUT, peaking filter, histogram, vector scope, audio meter, time code, image flip, etc. All these functions are easy to select and operate from the OSD menu. FEATURES 12G-SDI /8K/4K HDMI Signal4K IPS LCD PanelProfessional On Set Monitoring Tools (eg ARRI/RED false color)Flexible and Intuitive Button OperationAccurate 3D LUT Color CalibrationSupport HDR waveformMultiple Screen ModesImproved intuitive control buttonsSDR and HDR Image Comparison Function12G-SFP Fiber PortUSB-C (Thounderbolt) input PortAluminum Alloy FramePayload ID Automatically Read3D LUT, Recreate Film LooksDynamic UMDThree Color Tally LightsProfessional Audio MetersRemovable feet and handles on the back side24V DC XLR power imput (V-Mount batter plate optional)VESA mounting points TECHNICAL DATAScreen Size: 23,8"Brightness: 1000nitColor Depth: 10BitResolution: 3840x2160Aspect Ratio: 16:9Contrast Ratio: 1000:1Backlight: LEDResponsetime: 9msViewing Angle: 178°Screen Gamut: 98% DCI-P3SDI Interface: 4x 12G-SDI (support 8K input)HDMI Interface: 2x HDMI 2.0Other Interface: 1x Type C, 1x SFP, 1x LAN, 1x GPI, RS422 In & OutTally: Front3D LUT: Tetrahedral interpolation, User LUTHDR: PQ + HLGEETF: YesStill Image Detection: SupportedGamma: Gamma 2.0, 2.2, 2.4 & 2.6; SMTP ST 2084(PQ); ITU-R; BT.2100(HLG); S-Log3, Canon LogCamera Log: Sony, Canon, ARRI, DJIGamut Comparison: SDR and HDR Image ComparisonGamut Warning: YesMulti-View: Quad view, Quadview triple side, Quadvie triple bottom, PBP, PAPUMD: 3.1, 4.1, 5.0Monitoring Tools: Waveform, Vectorscope, HistogramTime Code: YesInput Voltage: AC 100V~240VPower Consumption: Max. 90WWorking Temperature: -10°C ~ 55°CStorage Temperature: -20°C ~ 60°CSize (LxHxD): 571,7 x 414,85 x 160mmWeight: 8,6 kg

RGBlink Aura UHD 32 Gen 2 12G-SDI Professional 32" UHD Film and Television Production Monitor. This next generation 32" broadcast/grading 4K HDR monitor, equipped with UHD (3840×2160) screen, supports quad link 12G SDI signal up to 8K input backward compatible with 4K@60Hz, high-precision 3DLUT with tetrahedral interpolation algorithm, HDR formats such as SMPTE ST2084(PQ), hybridlog-gamma HLG, various Gamma curves, camera Log and other professional functions which are widely used in film, television and advertisement industry. Screen Size: 31,5"Brightness: 1000nitColor Depth: 10BitResolution: 3840x2160Aspect Ratio: 16:9Contrast Ratio: 1000:1Backlight: LEDResponsetime: 9msViewing Angle: 178°Screen Gamut: 98% DCI-P3SDI Interface: 4x 12G-SDI (support 8K input)HDMI Interface: 2x HDMI 2.0Other Interface: 1x Type C, 1x SFP, 1x LAN, 1x GPI, RS422 In & OutTally: Front3D LUT: Tetrahedral interpolation, User LUTHDR: PQ + HLGEETF: YesStill Image Detection: SupportedGamma: Gamma 2.0, 2.2, 2.4 & 2.6; SMTP ST 2084(PQ); ITU-R; BT.2100(HLG); S-Log3, Canon LogCamera Log: Sony, Canon, ARRI, DJIGamut Comparison: SDR and HDR Image ComparisonGamut Warning: YesMulti-View: Quad view, Quadview triple side, Quadvie triple bottom, PBP, PAPUMD: 3.1, 4.1, 5.0Monitoring Tools: Waveform, Vectorscope, HistogramTime Code: YesInput Voltage: AC 100V~240VPower Consumption: Max. 140WWorking Temperature: -10°C ~ 55°CStorage Temperature: -20°C ~ 60°CSize (LxHxD): 751 x 502 x 179mmWeight: 15,3 kg
