Z CAM E2-S6 Mark II

Z CAM E2-S6 Mark II SUPER 35mm 6K CINEMA CAMERA

SKU: ZCE2S6M2

The Z CAM E2-S6 Mark II comes with a Super 35mm CMOS sensor, offering flexibility in professional production settings. It supports 6K recording at up to 60 frames per second and 4K at up to 100 frames per second. With its dynamic range of 14 stops, it delivers exceptional image quality for artistic and commercial projects. This model also features a native ISO range starting at 400, making it suitable for a variety of lighting conditions. The EF mount is standard but can be replaced with PL, M, or MFT mounts for maximum compatibility with different lenses.

Features

  • Super 35mm CMOS sensor for professional use
  • 6K video recording at up to 60 fps, 4K at up to 100 fps
  • Dynamic range of 14 stops
  • Supports ProRes 4:2:2, H.265, and ZRAW formats
  • Native ISO range starting at 400 for versatile lighting conditions
  • Standard EF mount, compatible with optional PL, M, and MFT mounts
  • Built-in gyroscope sensor for enhanced stabilization
  • Power over Ethernet (PoE+) and Genlock support for multi-camera setups
  • Storage on CFexpress Type-B cards

Technical data

Camera

  • Sensor Type: Super 35mm CMOS Sensor
  • Sensor Size: 23.5 x 15.7 mm (Diagonal 28.3mm)
  • Effective Pixels: 26.11M
  • Dynamic Range: 14 stops
  • Lens Mount: EF Mount w/active lock (interchangeable to optional PL, LPL and M)
  • Microphone: Built-in Stereo Microphone

Recording

  • Video Encoder: H.264 / H.265 / ProRes 422 Proxy / ProRes 422 LT / ProRes 422 / ProRes 422 HQ / ZRAW*
  • RAW over HDMI: ProRes RAW (using Atomos Ninja V); BRAW (using BMD VideoAssist)
  • Color Bit-depth: 10-bit 4:2:0 (H.265) / 8-bit 4:2:0 (H.264)
  • Audio Format" 16-bit 48 kHz
  • Audio Encoder: AAC / PCM (for MOV only)
  • File Format: MOV / MP4
  • Record Mode: Video / Time Lapse Video / Still Image Capture
Resolution & Max Frame Rate
  • 30fps max @ Open Gate (6244x4168)
  • 48fps max @ C6K (6144x3240)
  • 60fps max @ 6K 2.4:1 (6144x2592)
  • 48fps max @ 6K (5760x3240)
  • 30fps max @ 5K 4:3 (5552x4164)
  • 50fps max @ 5528x3112
  • 60fps max @ C5K (5120x2700)
  • 30fps max @ 5K 6:5 (4992x4160)
  • 60fps max @ 5K (4800x2700)
  • 30fps max @ C4K 3:2 (4096x2732)
  • 30fps max @ C4K Low Noise (4096x2160)
  • 75fps max @ C4K (4096x2160)
  • 100fps max @ C4K 2.4:1 (4096x1728)
  • 30fps max @ 4000x4000
  • 30fps max @ 3840x3840
  • 30fps max @ 4K Low Noise (3840x2160)
  • 75fps max @ 4K (3840X2160)
  • 50fps max @ 3456x3456
  • 90fps max @ S16 16:9 (3392x1908)
  • 120fps max @ 2.8K (2868x1512)
  • 120fps max @ 1920x1080

* supersampling / cropping selectable, 4K supersampling is supported at the same frame rates as C6K resolution mode
