Datavideo DAC-91 SDI Audio Embedder

Skip image gallery
Datavideo DAC-91 SDI Audio Embedder
Datavideo DAC-91
SDI Audio Embedder
Datavideo DAC-91 SDI Audio Embedder
Datavideo DAC-91
SDI Audio Embedder

PLN 1,970.46*

net: PLN 1,602.00

Prices incl. VAT plus shipping costs

Product number: SW27013
Manufacturer: Datavideo
EAN: 672255006870
Manufacturer product number: 2000-2310
Delivery time: 3-5 days

Datavideo DAC-91

The Datavideo DAC-91 is an embedded audio box with useful functions that allow users to embed 2 channels of analogue audio into SDI video signal. It features 3G/HD/SD-SDI to support up to 1080p/60 video format, automatically detecting and switching between the different formats and provides mini XLR and RCA audio connectors for inputting analogue audio. The Audio box also has audio level adjustment by using the built-in DIP switches.

Features

  • Audio Embedder
  • Embed Audio into an SDI Signal
  • Automatically detects 3G, HD, SD signal
  • 4 x Analogue Audio inputs (Mini XLR x 2, RCA x 2)
  • Audio level indicator display
  • Audio level adjustment
  • Control via DIP Switches
