Voltage: 14,8 Volt Capacity: 9600mAh / 142Wh Cell type: Li-Ion Number of cells: 12 x 18650 LG Max. Power rating: 14A Overload protection: 16A P-Tap/D-Tap output voltage: max. 100W, 12.0V/8,3A / 16,8V/5,95A USB-connection: normal mode 5V/2,4A / fast charging mode: 9 V/2A maximum weight: 812 gr size: 75 x 105 x 83mm Brand: PATONA Platinum
Core SWX NANO Micro V-Mt
SKU: NANO-V98
The Core SWX NANO Micro is quite possibly the smallest style pack on the market today. Measuring in at less than 10,16 cm in height and 5,08 cmin depth, while weighing a feathery 0,54 kg., the Core SWX NANO-V98 is the perfect “grab and go” pack for the majority of powering applications. Capable of handling up to a 10A load, consider these packs for lighter camera powering applications, on-board monitors, recorders, wirless tx/rx, etc.
The 14.8v, 98wh capacity allows for the packs to be transported carry-on without restrictions under IATA, ICAO, and UN regulations. The packs have been UN tested and certified, passing UN38.3 certification.
The Core NANO packs feature an on-board unregulated p-tap which can be used to power most 12vdc devices, as well as doubling as a charge input port. The packs also include a 5V, 3A USB for powering/charging mobile devices, and a 4-stage LED gauge to view remaining power.
Features
98Wh, 14.8v 6.6Ah, 10A load li-ion battery pack - V-MountCapable of handling up to a 10A load4-stage LED gauge to view remaining powerFeature an on-board unregulated p-tap which can be used to power most 12vdc devicesInclude a 5V, 3A USB for powering/charging mobile devicesCan be transported carry-on without restrictions under IATA, ICAO, and UN regulations
PATONA Platinum NANO V50
Brand new to the PATONA Platinum series are our high-current NANO V-Mount batteries in a high-quality housing. Our batteries are equipped with the latest cell technology and have been specially designed to handle and maintain high power consumption. Protective circuits monitor cell equilibrium, temperature, overcharge and overdischarge to ensure safe and proper operation. Compared to normal V-Mount batteries, the new PATONA NANO V-Mount batteries have an approximately 30% smaller design with higher performance data. In addition, particular emphasis was placed on an appealing and modern design. A 4-stage LED display shows you the remaining capacity at any time. The P-Tap / D-Tap output can be used for lamps and many other external devices. Furthermore the USB output can also be used to charge smartphones and tablets, for example.
Technical Data
Voltage: 14,8 Volt Capacity: 3200mAh / 47Wh Cell type: Li-Ion Number of cells: 4 x 18650 LGMax. Power rating: 9A Overload protection: 10A P-Tap/D-Tap output voltage: max. 100W, 12.0V/8,3A / 16,8V/5,95AUSB-connection: normal mode 5V/2,4A / fast charging mode: 9 V/2A maximumweight: 316 gr size: 75 x 105 x 34mm Brand: PATONA Platinum
Core SWX CORE-N98S
New for 2017, the Core Nano series of Lithium ion battery packs replace the ever popular XPL90 series, which was the “go-to” battery solution across all professional video segments for nearly a decade. The packs offer the first economical solution that is “smart,” allowing SMBUS/AN % data to present on the EVFs of most industry cameras, and the AG packs are Anton/Bauer charger compatible. The series features a much slimmer design, consistent with the Hypercore Slim series. The packs are perfect for the majority of camera powering applications with a maximum load handling of 8A. Given the slim design, these packs can be also be used when powering cameras on handheld gimbals, and UAVs. The 14.8v, 98wh capacity allows for the packs to be transported carry-on without restrictions under IATA, ICAO and UN regulations. The packs have been UN tested and certified, passing UN38.3 certification. The Core SWX Nano packs feature an on-board unregulated P-tap which can be used to power most 12vdc devices, as well as doubling as a charge input port. The packs also include a 5V, 3A USB for powering/charging mobile devices. A rubberized, shock absorbent shell casing is used to provide the lightweight pack with greater protection against the rigors of everyday production. The Core Nano packs feature a 4-LED State of Charge power gauge. The Core Nano 98S V-mount battery, offers SMBUS data communication, which communicates with Sony, BMD, etc. and RED DSMC2 cameras, delivering the exact percentage of remaining capacity to the camera’s VF/LCD.
Core SWX Nano V-Mount technical data
Capacity: 98wh (14.8V, 6.6 Ah)Size: 9.65 cm x 14.91 cm x 3.78 cmWeight: 0.64 kgNormal Runtime: (25W) 3.6HrsMax Load: 8AP-tap and USB 5V
Core SWX Nano Micro 150 VM
The Nano Micro series offer some of the smallest style packs on the market today. The Nano Micro 150 measures in at less than 10,16 cm in height and 7,62 cm in depth, while weighing a feathery 0,7 kg, making it a perfect “grab and go” pack. Capable of handling up to a 12A continuous load, consider these packs for the majority of powering applications.
The packs feature an on-board unregulated p-tap which can be used to power most 12vdc devices, as well as doubling as a charge input port. The packs also include a 5V, 3A USB.
Features
147wh Micro size SMART battery pack14.8v 9.9Ah. 12A Draw (16A peak) with 4 LED GaugeIntegrated Ptap Port and USB, SMBUS Camera CommunicationSize: 9,98 cm x 7,19 cm x 6,68 cmWeight: 0,7 kgNormal Runtime (25W): 5.9 hoursLoad: 16A peak/12A continuous
PATONA Platinum NANO V95
The PATONA Platinum series was developed for a sensationally long lasting photo and film pleasure. The performance of the built-in cells is almost inexhaustible. In the PATONA Platinum series, the most advanced cells have been used, which have a quality that is not only extraordinary, but also impressive at the same time. The Platinum series is the highest quality, most durable and most innovative series from PATONA. By purchasing a battery from the PATONA Platinum series you acquire an excellent, exquisite product that will fascinate you.
Technical Data
Voltage: 14,8 Volt Capacity: 6400mAh / 95Wh Cell type: Li-Ion Number of cells: 8 x 18650 LGMax. Power rating: 11A Overload protection: 12A P-Tap/D-Tap output voltage: max. 100W, 12.0V/8,3A / 16,8V/5,95AUSB-connection: normal mode 5V/2,4A / fast charging mode: 9 V/2A maximumweight: 509 gr size: 75 x 105 x 50mm Brand: PATONA Platinum
PLN 1,034.49*
net: PLN 841.05
Pay with:
We ship with:
Fast shipping
Buy VAT exempt with your valid VAT EU ID
Purchase comfortable on account
Showroom in Warsaw +48 22 299 06 61
